| Printhead Tech. |
Drop on demand micro piezo-electric digital inkjet Printer |
| Printhead |
KM 512i-30PL |
| Printhead Quantity |
4-8 (Optional) |
| Print Speed (Express Mode) |
110* m²/hr (4 Heads) 230* m²/hr (8 Heads) |
| Print Speed (Standard Mode) |
80* m²/hr (4 Heads) 160* m²/hr (8 Heads) |
| Print Speed (Quality Mode) |
60* m²/hr (4 Heads) 120* m²/hr (8 Heads) |
| Media Type |
Flex, Vinyl Sheet, Canvas, Backlit, Banner, Window Film, One Way Vision etc. |
| Ink Color |
4 Color CMYK |
| Ink Type |
Solvent Ink |
| Media Width |
3,300 mm (10.8 ft) |
| Print Width |
3,200 mm (10.5 ft) |
| Computer System |
Windows 10 – 64 Bit / Windows 11 – 64 Bit |
| Image Format |
TIFF / JPEG / AI / PDF / PSD etc |
| Data Interface |
Hi-Speed USB 2.0 |
| RIP Software |
Photoprint / Maintop |
| Maximum Power |
3.5 kw |
| Power |
AC 220V, 50/60 Hz |
| Operational Environment |
Temperature : 20°C ~ 28°C, Humidity 40% RH ~ 60% RH |
| Machine Dimension |
43600 mm × 790 mm × 1170 mm |
| Package Dimension |
4820 mm × 1000 mm × 1570 mm |
