Specifications
| AUTOMATIC SPRAY BOOTH | |
| UV Coater | Automatic spray guns |
| Material Width | 4 feet |
| Feeding | Auto SS Roller Feeding Station |
| Spray Gun | 2 Automatic guns & 2 Manual guns |
| Guns Pressure | Air Pressure Controller with Separate Gauge |
| Booth Controller | PLC |
| Chemical supply | Auto air Controlled |
| Exhaust | High Power Suction Blower |
| Chemical reuse | Chemical collector tray |
| Booth length | 18 feet (approx) |
| Booth Width | 5 feet |
| UV CONVEYOR | |
| Width | 5 feet (approx) |
| Speed | Belt with Speed Controller |
| IR lamps unit | 1 |
| IR lamps | 1-3 (optional) |
| IR lamps Power | 3000watts/240volts with Temperature Controller |
| IR lamps Size | 1200mm |
| UV lamp unit | 1 |
| UV lamp | 1 |
| UV lamp Size | 1200mm |
| UV lamp Power | 300watt per inch |
| Lamp cooling | Blower |
| Delivery Station | 6 feet (approx) |
| Conveyor Length | 20 feet (approx) |
