Specifications
| Model | F-1810 |
| Printhead Tech. | Drop on demand micro piezo-electric digital inkjet Printer |
| Head Type | Epson i3200 / Ricoh Gen5i / Ricoh Gen5 (optional) |
| Head Quantity | 2-3 pcs (optional) |
| Media Thickness | 0-85mm |
| Print Size | 1800*1000mm |
| Ink Color | CMYK+CMYK/CMYK+W/CMYK+W+V/CMYKCMYK+W |
| RIP Software | PhotoPrint |
| Printer Software | Printer Express |
| Printer Speed | Sketch Mode: 720*600dpi-9*sqm/h Production Mode: 720*900dpi-8*sqm/h High Quality Mode: 720*1200dpi-6.5*sqm/h |
| Ink Supply Mode | Constant Pressure (Negative Pressure System) |
| Media Type | Wood panel, Aluminium panel, Glass, Ceramics, Acrylic, PVC, MDF etc. |
| Maximum Weight of Material | Panel: ≤ 45 kg/m2 |
| Data Interface | Hi-Speed USB 2.0 |
| Curing Mode | UV-LED Cold Light Source (with water chiller) |
| Image Format | TIFF/JPEG/AI/PDF/PSD etc |
| Computer System | Windows 10-64 Bit/ Windows 11-64 Bit |
| Maximum Power | >30A; 5KW |
| Machine Dimension | 2610mm x 2380mm x 1500mm |
| Package Dimension | 2860mm x 2460mm x 1680mm |
| Environment Requires | Dust-free environment with no direct sunlight and good ventilation. The optimal temperature is 18-22°C and the relative humidity is 30-70% |
