Specifications
| Model | UV-3060 |
| Printing Method | Drop on demand micro piezo-electric digital inkjet Printer |
| Head Type | Epson DX7 printhead |
| Max Print Size | 11.81″*23.62″ (30cm x 60cm) |
| Max Print Height | 180mm |
| Nozzle No | 1440dpi |
| Board | Hoson |
| Ink Type | UV Ink |
| Ink Colors | CMYK+W+V (optional) |
| Ink Supply | 100ml/Bottle |
| File Format | PDF, JPG, TIFF, EPS, AI, etc |
| Printing Quality | True Photographic Quality |
| Printing Direction | Bi-directional Printing Mode or Unidirectional Printing |
| Printing Speed | 8 PASS: 20 sqft/h 6 PASS: 30 sqft/h 4 PASS: 35 sqft/h |
| Max Media Weight | 30 KG |
| Height Adjustment | Manual |
| Media Feeding System | Manual |
| Software | Maintop / Photo Print |
| Operating System | WINDOWS 10 / WINDOWS 11 |
| Working Environment | 20-26 Degrees |
| Voltage | 110V / 220V |
| Power Consumption | 800w |
| Machine Size & Net Weight | 680*600*650mm 64kgs |
| Package Size & Gross Weight | 1040*880*800mm 100kgs |
