| Model |
F-2513 |
F-3220 |
| Max. Printing Size |
2500mm x 1300mm |
3200mm x 2000mm |
| Print Technology |
Drop on demand micro piezo-electric digital inkjet Printer |
| Print Head |
Ricoh Gen5 / Ricoh Gen6 |
| Print Resolution |
720 x 1200dpi(Max) |
720 x 1200dpi(Max) |
| Print Head Nos |
2-4 (optional) |
| Optional Color Configuration |
CMYK, CMYK W, CMYK WV, Double CMYK, CMYK V |
| Max. Media Thickness |
0-100mm |
| Print Speed (Express Mode) |
720*600dpi-4pass (15*sqm/hr) |
720*600dpi-4pass (30*sqm/hr) |
| Print Speed (Standard Mode) |
720*900dpi-6pass (12*sqm/hr) |
720*900dpi-6pass (25*sqm/hr) |
| Print Speed (Quality Mode) |
720*1200dpi-8pass (8*sqm/hr) |
720*1200dpi-8pass (17*sqm/hr) |
| Ink Supply System |
Negative Pressure Auto Ink Supply |
| Drying System |
UV Lamps Instant Drying |
| Media Absorption |
Vaccum Enabled |
| Table Pressure |
100kg/m² |
| Printable Media |
Glass, Ceramic, PVC, Wood, Metal, Sunboard,Sunpack, Acrylic, MDF, Doors & All Rigid Materials etc. |
| Interface |
HI SPEED USB 2.0 |
| Operating System |
Windows 10- 64 Bit/ Windows 11- 64 Bit |
| Image Format |
TIFF/JPEG/EPS/PDF/AI |
| Rip Software |
Photoprint /Onyx (optional) |
| Power / Maximum Power |
AC 220V , 50/60 Hz / >30A ; 6.5 KW |
| Operational Environment |
Temperature : 18°c ~ 22°c, Humidity 35% RH ~ 65% RH |
| Dimensions |
4620 x 2260 x 1620 (mm) |
5322 x 3160 x 1620 (mm) |
